axf:output-volume-break
(Auszug aus "XSL-FO ― Die Referenz" von Manuel Montero Pineda & Steffen Herkert, 2016, dpunkt.verlag)
A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z
Category PDF Output in Multi Separate Volume >> <axf:output-volume-info>
Separates the file in multi volume. [no-LT]
Value: | true | false |
Initial: | false |
Applies to: | fo:page-sequence |
Inherited: | no |
Percentages: | N/A |
Values have the following meanings.
true | Separates the volume newly from this fo:page-sequence. |
false | Do not separates the volume newly from this fo:page-sequence. |
Specifies axf:output-volume-break="true" to fo:page-sequence where you want to start separating the volume. The document number increases one by one. When separating the volume, axf:output-volume-break="true" is regarded as always being specified to the first fo:page-sequence. If axf:output-volume-break="false" is specified explicitly, it is ignored.
This property is not available with AH Formatter V6.3 Lite.
XSL-FO sample:
| <fo:root font-family="Arial Unicode MS" font-size="12pt" xmlns:fo="http://www.w3.org/1999/XSL/Format" xmlns:cpfo="http://www.compart.net/xmlns/cpfo" xmlns:svg="http://www.w3.org/2000/svg" xmlns:axf="http://www.antennahouse.com/names/XSL/Extensions"> | |
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| ||
| volume 1 page 1 | |
| </fo:block> | |
| ||
| volume 1 page 2 | |
| </fo:block> | |
| </fo:flow> | |
| ||
| ||
| ||
| ||
| volume 2 page 1 | |
| </fo:block> | |
| ||
| volume 2 page 2 | |
| </fo:block> | |
| </fo:flow> | |
| ||
| </fo:root> |
Output:
page 2
page 3
page 4
