axf:annotation-position-vertical
(Auszug aus "XSL-FO ― Die Referenz" von Manuel Montero Pineda & Steffen Herkert, 2016, dpunkt.verlag)
A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z
Category Annotation in PDF Output
Specifies the vertical position of the annotation. [no-LT]
Value: | <length> |
Initial: | 0pt |
Applies to: | all block-level and inline-level formatting objects |
Inherited: | no |
Percentages: | N/A |
The position specified is the distance from the top edge of the region and is used for the position of pop-up or icons and the position of rubber stamp annotations.
This property is not available with AH Formatter V6.3 Lite.
XSL-FO sample:
Output:
