Conditions

When formulating conditions, two elements are available in XSLT. One of them is the <xsl:if> element and the other is the <xsl:choose> element.

<xsl:if>

With the <xsl:if> element, conditions can be determined. The element is equipped with the obligatory test attribute which requires as a value an examination of the patterns. In contrast to other programming languages, there is no connection between IF and ELSE in XSLT. Let us have a look at a small example.

The stylesheet:

<?xml version="1.0" encoding="UTF-8"?>
<xsl:stylesheet version="1.0" xmlns:xsl="http://www.w3.org/1999/XSL/Transform">
<xsl:output encoding="iso-8859-1" version="1.0"/>
    <xsl:template match="CollectionOfPoems">
        <html>
           <body>
             <xsl:apply-templates/>
           </body>
        </html>
    </xsl:template>
    <xsl:template match="Author">
        <br/>
        <h4>
            <xsl:apply-templates/>
        </h4>
    </xsl:template>
    <xsl:template match="FirstName">
            <xsl:apply-templates/>
            <xsl:text> </xsl:text>
    </xsl:template>
    <xsl:template match="LastName">
            <xsl:apply-templates/>
    </xsl:template>
    <xsl:template match="Title">
        <h2>
            <xsl:apply-templates/>
        </h2>
    </xsl:template>
    <xsl:template match="Strophe">
        <p>
            <xsl:apply-templates/>
        </p>
    </xsl:template>
    <xsl:template match="Verse">
            <xsl:apply-templates/>
        <br/>
    </xsl:template>
    <xsl:template match="Poem">
        <br/>
        <xsl:if test="@Language='el'">The poem is in Greek.</xsl:if>   (1)
        <xsl:if test="@Language='en'">The poem is in English.</xsl:if>
        <xsl:if test="@Language='de'">The poem is in German.</xsl:if>
           <xsl:apply-templates/>
    </xsl:template>
</xsl:stylesheet>

(1) As you can see, the content of the <xsl:if> element is executed if the pattern in the test attribute finds a match in the source document.

Browser view of the target document:

Browser view: example - conditions

Exercise 4

Rewrite the stylesheet so that only Greek poems are displayed.

> > to the solution of exercise 4

<xsl:choose>

The <xsl:choose> element with its child elements <xsl:when> and <xsl:otherwise> corresponds to the "switch-case construct" in other programming languages.

With the help of this construct, various alternatives can be provided as well as a value, which is taken instead of alternatives being not applicable. The construct has to be introduced with the <xsl:choose> element. The element may contain any number of <xsl:when> child elements and exactly one <xsl:otherwise> element. The <xsl:when> elements as well as the <xsl:if> element have an obligatory test attribute. When its pattern matches, here also the content of the element is copied into the result tree. The main difference between the <xsl:if> element and the <xsl:choose>/<xsl:when> construct lies in the possibility of using the <xsl:otherwise> element, which takes action when none of the other <xsl:when> elements is applicable.

The stylesheet:

<?xml version="1.0" encoding="UTF-8"?>
<xsl:stylesheet version="1.0" xmlns:xsl="http://www.w3.org/1999/XSL/Transform">
  <xsl:output encoding="iso-8859-1" version="1.0"/>
    <xsl:template match="CollectionOfPoems">
        <html>
            <body>
                <xsl:apply-templates/>
            </body>
        </html>
    </xsl:template>
    <xsl:template match="Author">
           <br/>
           <h4>
               <xsl:apply-templates/>
          </h4>
    </xsl:template>
    <xsl:template match="FirstName">
              <xsl:apply-templates/>
              <xsl:text> </xsl:text>
    </xsl:template>
    <xsl:template match="LastName">
              <xsl:apply-templates/>
    </xsl:template>
    <xsl:template match="Title">
          <h2>
              <xsl:apply-templates/>
          </h2>
    </xsl:template>
    <xsl:template match="Strophe">
          <p>
              <xsl:apply-templates/>
          </p>
    </xsl:template>
    <xsl:template match="Verse">
              <xsl:apply-templates/>
              <br/>
    </xsl:template>
    <xsl:template match="Poem">
              <br/>
              <xsl:choose>                                                           (1)
                  <xsl:when test="@Language='el'">The poem is in Greek.</xsl:when>
                  <xsl:when test="@Language='en'">The poem is in English.</xsl:when> (2)
                  <xsl:otherwise>The poem is in German.</xsl:otherwise>              (3)
             </xsl:choose>
             <xsl:apply-templates/>
    </xsl:template>
</xsl:stylesheet>

(1) The <xsl:choose> element encloses the construct. The <xsl:when> and <xsl:otherwise> elements are only permitted as child elements of the <xsl:choose> element.

(2) The <xsl:when> element is executed if the pattern is applicable in the test attribute. In this case it is verified if the content of the current node – which means @Language – has the value „en“. If the value matches with the pattern, the text "The poem is in English." is outputted.

(3) The <xsl:otherwise> element is used if none of the <xsl:when> elements applies.
